COMMENCAL META V5 RACE SPARKLY BLUE

FRAME MATERIAL: AL 6066 T4, T6

FRAME WEIGHT: 4,06 kg / 8,95 lb

REAR TRAVEL: 150 mm

SHOCK LENGTH / STROKE: 210 x 55 mm

PIGGY BACK SHOCK COMPATIBLE: YES

SHOCK BUSHINGS: 20x10mm / no bushing needed on clevis

RECOMMENDED / MAX. FORK HEIGHT: 571mm / 586mm

HEADSET DIMENSION: TAPERED 1-1/8" / 1-1/2"

HEADSET TYPE: ZS56 / ZS56

MAXIMUM TYRE DIMENSION (ETRTO): 65mm - Ø622mm

DISC BRAKE STANDARD: POSTMOUNT 200 MM

REAR ROTOR MAX. SIZE: 223 MM

SEATPOST / SEAT CLAMP DIAMETER: 34,9 MM / 38,5 MM

BOTTOM BRACKET TYPE: PRESS FIT BB 92

ISCG: ISCG 05

FRONT DERAILLEUR TYPE: NO

REAR HUB COMPATIBILITY: 148 X 12 MM

SHOCK: OHLINS TTX22M Coil
210 x 55 mm, HSC, LSC, rebound. Spring rates: 388 on S, 434 on M, 480 on L, 525 on XL

FORK: ROCKSHOX Lyrik Ultimate, 160 mm travel
29", Charger 3 RC2 W/ButterCups damper, DebonAir+ W/ButterCups, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset, 0 Token

HEADSET: ACROS ZS56 / ZS56
Alloy cups, sealed bearings

STEM: RIDE ALPHA 40
40 mm extension, 31,8 mm

BAR: RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS: ODI LONGNECK
Soft compound, single clamp, black

BRAKES: TRP DH-R EVO, 4 pistons, Postmount
Rotor: TRP R1 203 mm, 6-bolts

SHIFTERS: SRAM GX Eagle
12s

CHAIN GUIDE: RIDE ALPHA
32t-34t

REAR MECH: SRAM GX Eagle
12s

BOTTOM BRACKET: SRAM DUB WIDE
Pressfit

CRANKSET: SRAM GX Eagle, 170 mm crank arms, DUB, Boost
Chainring: SRAM Eagle, 32t, Narrow-Wide

CHAIN: SRAM GX Eagle
12s

CASSETTE: SRAM XG-1275 Eagle
12s, 10-52t

RIMS: CRANK BROTHERS Synthesis Alloy Enduro 3
Rear: 29'', 32h, 29.5 mm inner width - Front: 29'', 28h, 31.5 mm inner width

HUBS: INDUSTRY NINE 1/1
Rear: 32h, sealed bearings, 12 x 148 mm, 4º, XD driver, black - Front: 28h, sealed bearings, 15 x 110 mm, black

SPOKES/NIPPLES: Rear: SAPIM Race - Front: SAPIM D-Light
Rear: J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black - Front: J-Bend, 2.0-1.65-2.0mm, double butted, stainless, with Nylok, black

TYRES: Rear: MAXXIS DHR II - Front: MAXXIS DHR II
Rear: 29"x2.40" WT, EXO, Dual, Tubeless Ready - Front: 29"x2.40" WT, EXO, 3C MaxxGrip, Tubeless Ready

SEATPOST: KS Lev Integra
34.9 mm, travel: 125 mm on S, 175 mm on M/L and 200 mm on XL, SouthPaw alloy remote

SADDLE: FIZIK Terra Alpaca X5
145 mm width, S-alloy rails

BICYCLE TYPE: Enduro / All Mountain

FRAME: META V5, 150 mm travel
29'', Alloy 6066, triple butted tubes, T4, T6

WEIGHT: 15,7 kg / 34.61 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED: NO

ACCESSORIES: Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender
