COMMENCAL META SX V5 SIGNATURE PURE WHITE 2026

FRAME MATERIAL: AL 6066 T4, T6

FRAME WEIGHT: 4,08 kg / 8,99 lb

REAR TRAVEL: 165 MM

SHOCK LENGTH / STROKE: 230x65mm

PIGGY BACK SHOCK COMPATIBLE: YES

SHOCK BUSHINGS: 20x10mm / no bushing needed on clevis

RECOMMENDED / MAX. FORK HEIGHT: 586mm / 598mm

HEADSET DIMENSION: STRAIGHT

HEADSET TYPE: ACROS ZS56/ZS56 Alloy cups, sealed bearings

MAXIMUM TYRE DIMENSION (ETRTO): 65mm - Ø622mm65mm - Ø584mm

DISC BRAKE STANDARD:

REAR ROTOR MAX. SIZE: 223mm

SEATPOST / SEAT CLAMP DIAMETER: 34,9mm / 38,5mm

BOTTOM BRACKET TYPE: Press Fit BB 92mm

ISCG:

FRONT DERAILLEUR TYPE: NO

REAR HUB COMPATIBILITY: 12 X 148 MM

SHOCK: FOX Float X2 Factory
230 x 65 mm, HSC, HSR, LSR, 2-pos lever, 0.3 spacer

FORK: FOX 38 Factory, 170 mm travel
29", rebound, Boost (15 x 110 mm), HSC, LSC, HSR, LSR, 44mm offset, 1 Token

HEADSET: ACROS ZS56/ZS56
Alloy cups, sealed bearings

STEM: RIDE ALPHA 40
40 mm extension, 31.8 mm

BAR: RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS: ODI Longneck V2.1
Black clamp

BRAKES: SHIMANO New XT, 4 pistons, resin pads
Rotors: SHIMANO MT905, 203 mm, 6-bolts

SHIFTERS: SRAM Eagle 90
12s

CHAIN GUIDE: RIDE ALPHA
32-34t

REAR MECH: SRAM Eagle 90
12s

BOTTOM BRACKET: SRAM DUB92 MTB WIDE
Pressfit

CRANKSET: SRAM X0 T-Type, 165 mm crank arms
Chainring: SRAM X0 T-Type, 32t

CHAIN: SRAM GX T-Type
12s

CASSETTE: SRAM GX T-Type
12s, 10-52t

RIMS: DT SWISS EX1700
Rear: 27.5'', 32h, 28 mm inner width - Front: 29'', 32h, 28 mm inner width

HUBS: DT SWISS 350
Rear: 32h, sealed bearings, 12 x 148 mm, Sram XD - Front: 32h, sealed bearings, 15 x 110 mm

SPOKES/NIPPLES: Included with wheelset

TYRES: Rear: MAXXIS DHR II - Front: MAXXIS Assegai
Rear: 27.5''x2.5'' WT, 3C MaxxTerra, New EXO+, Tubeless Ready - Front: 29''x2.5'' WT, 3C MaxxGrip, New EXO+, Tubeless Ready

SEATPOST: ONE UP V3
31,6 mm, travel: 125 mm on S, 170 mm on M and 190 mm on L/XL, SouthPaw alloy remote

SADDLE: FIZIK Terra Ridon X5
145 mm, Alloy rails

BICYCLE TYPE: Enduro

FRAME: 2025 META SX V5, 165 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings

WEIGHT: 16,3 kg / 35.93 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED: No

ACCESSORIES: Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender, FIDLOCK base, seatpost adapter.
