COMMENCAL T.E.M.P.O. POWER ESSENTIAL 2025

FRAME MATERIAL: AL 6069 T6

FRAME WEIGHT: 3,84 kg / 8,46 lb

REAR TRAVEL: 135 MM

SHOCK LENGTH / STROKE: 210x50mm

PIGGY BACK SHOCK COMPATIBLE: YES

SHOCK BUSHINGS: 20x10mm - 30x10mm

RECOMMENDED / MAX. FORK HEIGHT: 551mm / 561mm

HEADSET DIMENSION: STRAIGHT

HEADSET TYPE: ZS56 / ZS56

MAXIMUM TYRE DIMENSION (ETRTO): 65mm - Ø622mm

DISC BRAKE STANDARD:

REAR ROTOR MAX. SIZE: 203mm

SEATPOST / SEAT CLAMP DIAMETER: 31,6 MM / 34,9 MM

BOTTOM BRACKET TYPE: BOSCH E-BIKE

ISCG: Yes (BOSCH Standard)

FRONT DERAILLEUR TYPE: NO

REAR HUB COMPATIBILITY: 12 X 148 MM

SHOCK: FOX Float Performance
210 x 50 mm, rebound, 2-postion (open/firm) lever, 3-setting open mode tuning range, 0.6 spacers

FORK: FOX 36 Performance E-Bike, 150 mm
29", Grip damper, rebound, LSR, 3-position compression, Boost (15 x 110 mm), 44 mm offset, 4 spacers

HEADSET: ACROS ZS56/ZS56
Alloy cups, sealed & stainless steel bearings

STEM: RIDE ALPHA 40
40 mm extension, 31.8 mm

BAR: RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL

GRIPS: RIDE ALPHA Mushroom
Soft compound, single clamp, 132 mm width, black

BRAKES: SHIMANO Deore, 4 pistons, resin pads
Rotors: SHIMANO SM-RT86 203 mm, 6-bolt

SHIFTERS: SHIMANO Deore
12s

CHAIN GUIDE: RIDE ALPHA
32-34 T

REAR MECH: SHIMANO Deore
12s

BOTTOM BRACKET: BOSCH

CRANKSET: E13 Helix Core e*spec, 155 mm crank arms
Rotors: E13 Helix Race e*spec, 34t, direct mount

CHAIN: SHIMANO Deore
12s

CASSETTE: SHIMANO Deore
12s, 10-51t

RIMS: DT SWISS H 1900 LS
29'', 28h, 30 mm inner width, Tubeless Ready

HUBS: DT SWISS 370
Rear: 28h, 12 x 148 mm, sealed bearings, 18t, e-bike specific, Shimano Hyperglide - Front: 28h, 15 x 110 mm, sealed bearings

SPOKES/NIPPLES: DT SWISS Hybrid 1
Straightpull, 2.34 / 2.0 mm, double butted, stainless, with ProLock, black

TYRES: Rear: SCHWALBE Tacky Chan - Front: SCHWALBE Magic Mary
Rear: 29"x2.4", Evo, Super Trail, Addix Soft, Tubeless Easy - Front: 29"x2.4", Evo, Super Trail, Addix Ultra Soft, Tubeless Easy

SEATPOST: KS Ragei
31.6 mm, 125 mm on S, 170 mm on M, 190 mm on L /XL

SADDLE: FIZIK Terra Ridon X5
145 mm width, S-Alloy Mobius rails

MOTOR: BOSCH Performance Line CX. Max. torque: 85N.m, 250W

BATTERY: BOSCH PowerTube 625, 625Wh. BOSCH 4A Charger, Compact size & lightweight. Compatible w/Bosch PowerMore 250 for extra range

DISPLAY: BOSCH System ControllerBOSCH Mini Remote currently not available in the USA

BATTERY RECYCLING: Partnership with BOSCH. The battery (used up, damaged, defective) must be recycled. Each national distributor is responsible for providing the dealer with a free recycling solution.
Applicable laws: Battery Act, Directive 2006/66/EC, BattG in Germany too. Robert Bosch GmbH recommends concluding a contract with a national service provider for returning batteries in each case.

BICYCLE TYPE: E-bike - Trail / Aventure

FRAME: T.E.M.P.O. POWER, 135 mm travel
29'', Alloy 6066 triple butted tubes, T4, T6. Bolu bearings

WEIGHT: 20,4 kg / 45 lbs
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.

PEDALS INCLUDED: CRANKBROTHERS Stamp 1 pedals

ACCESSORIES: Down tube protector, chainstay protector, seatstay protector, pedals, FOX 36 specific fender, Fidlock bases, down tube plastic film protector
